Technical Specifications
Access Control
- Source/Destination IP-Based ACL
- Stateful ACL
- IPv4/IPv6 ACL
- Location Based ACL
Filtering
- WEB Group Filtering
- URL Filtering
- Web Security
ARP Inspection
- Sending GARP Packets
- ARP Scanning
- IP-MAC Binding
Attack Defence
- TCP/UDP/ICMP Flood Defence
- Block TCP Scan (Stealth FIN/Xmas/Null)
- Block Ping from WAN
Hardware Features
Standards and Protocols
- IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE802.1q
- TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMP
Interface
- 1 x 2.5G RJ45 WAN/LAN Port
- 1 x 2.5G RJ45 WAN/LAN Port
- 2 x Gigabit SFP WAN/LAN Ports
- 8 x Gigabit RJ45 WAN/LAN Ports
- 1 x RJ45 Console Port
- 1 x USB 3.0 Port (Supports USB storage, and LTE backup with LTE dongle)
Network Media
- 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100O STP (Max 100 m)
- 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100O STP (Max 100 m)
- 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
- 2500BASE-T: UTP category 5e, 6 cable (Max 100 m)
Button
Power Supply
Flash
DRAM
Dimensions (W x D x H)
- 294 x 180 x 44 mm (11.6 x 7.1 x 1.7 in.)
Protection
Enclosure
Mounting
Max Power Consumption
- 18.5W (With USB 3.0 connected)
Performance
GRE
- Unencrypted: 1153.0 Mbps
- Encrypted: 559.2 Mbps
WireGuard VPN
Concurrent Session
New Sessions / Second
NAT (Static IP)
- 2345.71 Mbps / 2351.22 Mbps
NAT(DHCP)
- 2353.41 Mbps / 2353.40 Mbps
NAT(PPPoE)
- 2336.52 Mbps / 2336.08 Mbps
NAT (L2TP)
- 1937.53 Mbps / 1761.82 Mbps
NAT (PPTP)
- 1757.54 Mbps / 2011.33 Mbps
IPsec VPN Throughput
- ESP-SHA1-AES256: 1125.60 Mbps
- ESP-SHA256-AES256: 1133.1 Mbps
- ESP-SHA384-AES256: 1126.6 Mbps
- ESP-SHA512-AES256: 1132.8 Mbps
OpenVPN
L2TP VPN Throughput
- Unencrypted: 2724.5 Mbps
- Encrypted: 1018.4Mbps
VLANIPTV
- IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
Advanced Functions
Advanced Routing
- Static Routing
- Policy Routing
- RIP (available in Standalone Mode)
- OSPF (available in Standalone Mode)
Bandwidth Control
- IP/Port-based Bandwidth Control
Load Balance
- Intelligent Load Balance
- Application Optimised Routing
- Link Backup (Timing, Failover)
- Online Detection
NAT
- One-to-One NAT
- Multi-Net NAT
- Virtual Server
- Port Triggering
- NAT-DMZ
- FTP/H.323/SIP/IPSec/PPTP ALG
- UPnP
Session Limit
VPN
GRE
SSL VPN
IPsec VPN
- 150 IPSec VPN Tunnels
- LAN-to-LAN, Client-to-LAN
- Main, Aggressive Negotiation Mode
- DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
- IPsec Failover
- IKE v1/v2
- MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
- NAT Traversal (NAT-T)
- Dead Peer Detection (DPD)
- Perfect Forward Secrecy (PFS)
PPTP VPN
- PPTP VPN Server
- PPTP VPN Client (15)
- 150 Tunnels
- PPTP with MPPE Encryption
L2TP VPN
- L2TP VPN Server
- L2TP VPN Client (15)
- 150 Tunnels
- L2TP over IPSec
OpenVPN
- OpenVPN Server
- OpenVPN Client (11)
- 121 OpenVPN Tunnels
- "Certificate + Account" Mode
- Full Mode
Authentication
Web Authentication
- No Authentication
- Simple Password
- Hotspot (Local User/Voucher/SMS/Radius)
- External Radius Server
- External Portal Server
- LDAP
Management
Omada App
- Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralised Management
- Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller
Cloud Access
- Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Service
- Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customisation)
Maintenance
- Web Management Interface
- Remote Management
- Export & Import Configuration
- SNMP v1/v2c/v3
- Diagnostics (Ping & Traceroute)
- NTP Synchronise
- Port Mirroring
- CLI (only in Standalone Mode)
- Syslog Support
Zero-Touch Provisioning
- Yes. Requiring the use of Omada Cloud-Based Controller.
Management Features
