TP Link SG3428XMPP Omada 24-Port Gigabit and 4-Port SFP+ L2+ Managed Switch with

Technical Specifications

Hardware Features

Interface

• 24 x 10/100/1000 Mbps RJ45 Ports (8 x PoE++, 16 x PoE+)
• 4 x 10G SFP+ Slots
• 1 x RJ45 Console Port
• 1 x Micro-USB Console Port

Fan Quantity

• 3

Physical Security Lock

• Yes

Power Supply

• 100-240 V AC~50/60 Hz

PoE Ports (RJ45)

• Standard: 802.3at/af/bt compliant
• PoE++ Ports: Ports 1~8 (up to 90 W PoE Output per Port)
• PoE+ Ports: Ports 9~24 (up to 30 W PoE Output per Port)
• Power Budget: 500 W

Dimensions (WxDxH)

• 17.3 x 13.0 x 1.7 in (440 x 330 x 44 mm)

Mounting

• Rack Mountable

Max Power Consumption

• 605.5W (110V/60Hz) (with 500W PD connected)

Max Heat Dissipation

• 2064.96 BTU/hr (110 V/60 Hz) (with 500W PD connected)

Performance

Switching Capacity

• 128 Gbps

Packet Forwarding Rate

• 95.23 Mpps

MAC Address Table

• 16 K

Packet Buffer Memory

• 12 Mbit

Jumbo Frame

• 9 KB

Software Features

Quality of Service

• 8 priority queues
• 802.1p CoS/DSCP priority
• Queue scheduling: SP (Strict Priority), WRR (Weighted Round Robin), SP+WRR
• Bandwidth Control: Port/Flow-based Rating Limiting
• Smoother Performance
• Action for Flows: QoS remark (802.1P Remark, DSCP Remark)

L2 and L2+ Features

• 128 IP Interfaces: Support IPv4/IPv6 Interface
• Static Routing: 48 IPv4/IPv6 Static Routes
• Static ARP: 128 static entries
• 512 ARP Entries
• Proxy ARP
• Gratuitous ARP
• DHCP Server
• DHCP Relay: DHCP Interface Relay, DHCP VLAN Relay
• DHCP L2 Relay
• Link Aggregation
• Spanning Tree Protocol
• Loopback Detection
• 802.3x Flow Control
• Mirroring

L2 Multicast

• Supports 1000 (IPv4, IPv6) IGMP groups
• IGMP Snooping
• IGMP Authentication
• Multicast VLAN Registration (MVR)
• MLD Snooping
• Multicast Filtering: 256 profiles and 16 entries per profile

Advanced Features*

• Automatic Device Discovery
• Batch Configuration
• Batch Firmware Upgrading
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule

ISP Features**

• L2PT (Layer 2 Protocol Tunnelling)
• Device Link Detect Protocol (DLDP)
• PPPoE ID Insertion
• ERPS
• 802.3ah Ethernet Link OAM
• DDM
• sFlow

VLAN

• VLAN Group: Max 4K VLAN Groups
• 802.1q Tagged VLAN
• MAC VLAN: 30 Entries
• Protocol VLAN: Protocol Template 16, Protocol VLAN 16
• Private VLAN
• GVRP
• VLAN VPN: VLAN Mapping, VLAN Replace
• Voice VLAN

Access Control Lis

Security

• IP-MAC-Port Binding
  • 512 Entries
  • DHCP Snooping
  • ARP Inspection
  • IPv4 Source Guard: 100 Entries
• IPv6-MAC-Port Binding
  • 512 Entries
  • DHCPv6 Snooping
  • ND Detection
  • ND Snooping
  • IPv6 Source Guard: 100 Entries
• DoS Defend
• DHCP Filter
• Static/Dynamic Port Security: Up to 64 MAC addresses per port
• Broadcast/Multicast/Unicast Storm Control: kbps/ratio/pps control mode
• 802.1X
  • Port-based authentication
  • Mac-base authentication
  • VLAN Assignment
  • MAB
  • Guest VLAN
  • Radius authentication and accountability support
• AAA (including TACACS+)
• Port Isolation
• Secure web management through HTTPS with SSLv3/TLS 1.2
• Secure Command Line Interface (CLI) management with SSHv1/SSHv2
• IP/Port/MAC-based access control

IPv6

• IPv6 Dual IPv4/IPv6
• Multicast Listener Discovery (MLD) Snooping
• IPv6 ACL
• IPv6 Interface
• Static IPv6 Routing
• IPv6 neighbour discovery (ND)
• Path maximum transmission unit (MTU) discovery
• Internet Control Message Protocol (ICMP) version 6
• TCPv6/UDPv6
• IPv6 applications: DHCPv6 Client, Ping6, Tracert6, Telnet (v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP

MIBs

• MIB II (RFC1213)
• Interface MIB (RFC2233)
• Ethernet Interface MIB (RFC1643)
• Bridge MIB (RFC1493)
• P/Q-Bridge MIB (RFC2674)
• RMON MIB (RFC2819)
• RMON2 MIB (RFC2021)
• Radius Accounting Client MIB (RFC2620)
• Radius Authentication Client MIB (RFC2618)
• Remote Ping, Traceroute MIB (RFC2925)
• Support TP-Link private MIBs

Management

Omada App*

• Yes (requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller)

Centralised Management

• Omada Cloud-Based Controller
• Omada Hardware Controller (see accessories tab)
• Omada Software Controller

Cloud Access*

• Yes (requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller)

Zero-Touch Provisioning*

• Yes (requires the use of Omada Cloud-Based Controller)

Management Features

• Web-based GUI
• Command Line Interface (CLI) through console port, telnet
• SNMPv1/v2c/v3
  • Trap/Inform
  • RMON (1, 2, 3, 9 groups)
• SDM Template
• DHCP/BOOTP Client
• 802.1ab LLDP/LLDP-MED
• DHCP AutoInstall
• Dual Image, Dual Configuration
• CPU Monitoring
• Cable Diagnostics
• EEE
• Password Recovery
• SNTP
• System Log

Others

Certification

• CE, FCC

System Requirements

• Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/10/11, MAC OS, NetWare, UNIX or Linux.

Environment

• Operating Temperature: 0°C – 40°C (32°F – 104°F)
• Storage Temperature: -40°C – 70°C (-40°F – 158°F)
• Operating Humidity: 10% &ndas
