TP Link SG108-M2 5-Port 2.5G Desktop Switch

Product Ref: TL-SG108-M2

MPN: 68913

  • Eight (8) 2.5 Gbps Ports: 2.5-Gigabit ports unlock the highest performance of your Multi-Gig bandwidth and devices, and provide up to 25 Gbps of switching capacity.
  • Super-Fast Connections: Provides super-fast connections to 2.5G NAS, 2.5G Server, gaming computer, 2.5G WiFi 6 AP, 4K video, and more.
  • Ideal for Various Scenarios: Built for LAN parties, home entertainment, small and home offices, and instant transfer for workstations,
  • Hassle-Free Cabling: Instantly upgrade to 2.5 Gbps without the need to upgrade to CAT6 wiring, reducing wiring costs and hassle.
  • Silent Operation: Industry-leading fanless design ensures silent operation, ideal for any home or business.
  • Plug and Play: Allows for easy deployment without the need for a technician.
  • Metal Casing: Durable metal casing and desktop/wall-mounting design are well-suited for different environments.

Technical Specifications

Interface

  • 8 x 100Mbps/1G/2.5G
  • Auto-Negotiation, Auto MDI/MDI-X

Performance

Switching Capacity

  • 40 Gbps

Packet Forwarding Rate

  • 29.8 Mpps

MAC Address Table

  • 16K

Packet Buffer

  • 1.5 Mbit

Transfer Method

  • Store and Forward

Jumbo Frame

  • 10K

Advance Features

  • 802.3x flow control
  • 802.1p/DSCP QoS

Physical & Environment

Power Supply

  • 12 V/1.5 A Adapter

Max Power Consumption

  • 15.65 W

Max Heat Dissipation

  • 53.40 BTU/hr

Dimensions (W x D x H)

  • 226 x 131 x 35 mm

Fan Quantity

  • Fanless

Installation

  • Desktop/Wall Mounting

Operating Temperature

  • 0°C to 40°C (32 °F to 104 °F)

Storage Temperature

  • -40 °C to 70 °C (-40 °F to 158 °F)

Operation Humidity

  • 10% to 90% RH, non-condensing

Storage Humidity

  • 5% to 90% RH, non-condensing

Certification

  • CE, FCC, RoHS
