Technical Specifications
Hardware Features
Interface
Button
Power Supply
- 802.3at PoE or 12V/1.5A DC (Power Adapter Is Not Included)
Power Consumption
- 18.6 W (For PoE)
- 16.0 W (For DC)
Dimensions (W x D x H)
- 160 x 160 x 36.7 mm (6.3 x 6.3 x 1.4 in.)
Antenna Type
- 2.4 GHz: 2 x 4.0 dBi
- 5 GHz: 2 x 5.0 dBi
Mounting
- Ceiling / Wall Mounting (Kits Included)
Wireless Features
Coverage
Wireless Client Capacity
Wireless Standards
- IEEE 802.11 a/b/g/n/ac/ax/be
Frequency
Signal Rate
- 688 Mbps (2.4 GHz) + 2882 Mbps (5 GHz)
Wireless Functions
- 4K-QAM
- Seamless Roaming
- MU-MIMO
- EHT160
- Mesh*
- OFDMA
- Load Balance
- Band Steering
- Beamforming
- Airtime Fairness
- Multiple SSIDS:16(8 on each band)
- Wireless Schedule
- Reboot Schedule
- QoS(WMM)
- Rate Limit
- Static IP/Dynamic IP
- RADIUS Accounting
- MAC Authentication
Wireless Security
- Captive Portal Authentication*
- Access Control
- Maximum number of MAC Filter: 4,000
- Wireless Isolation Between Clients
- VLAN
- Rogue AP Detection
- WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power
- < 20 dBm (2.4 GHz, EIRP)
- < 23 dBm (5 GHz, band 1&band 2, EIRP)
- < 28 dBm (5 GHz, band 3, EIRP)
Management
Omada App
Centralised Management
- Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller
Cloud Access
- Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller.
Email Alerts
LED ON/OFF Control
Management MAC Access Control
SNMP
System Logging Local/Remote Syslog
Web-based Management
Other Specifications
Certification
Environment
- Operating Temperature: 0°C – 40°C (32°F – 104°F)
- Storage Temperature: -40°C – 70°C (-40°F – 158°F)
- Operating Humidity: 10% – 90% non-condensing
- Storage Humidity:
