TP Link EAP623-OUTDOOR-HD Omada 1775Mbps WiFi 6 Wireless External Access Point
Product Ref: EAP623-OUTDOOR-HD
MPN: 88619
- Three (3) years free Omada Cloud Hosting service with broadbandbuyer.
- Zero-touch, pre-provisioned devices when you receive them. A true plug-and-go installation!
- Remotely manage multiple devices and sites from one easy-to-use interface.
- Install the Omada app on your phone for monitoring and managing your network
- Omada separates network management data from user data, with no user traffic passing through the cloud.
- Multi-person management, multi-level permissions, and the ability to add admins as needed
- Quickly see and troubleshoot connections at a glance.
- Free, dedicated UK technical support (9am-5pm Mon to Fri).
- Tailor the configuration of your devices to your business's needs.
- Monitor your network's statistics.
- Without the need for your own controller, save on IT resources.
- Not bound by a contract, you can choose to migrate your devices from our cloud controller at any time.
- Email alerting of faults and problems.
Technical Specifications
Hardware Features
Interfaces
- 1 x Gigabit Ethernet Port
Button
- Reset
Power Supply (sold separately)
- 802.3at PoE
- 48V Passive PoE
Dimensions (W x D x H)
- 106.5 x 57 x 281 mm (4.2 x 2.2 x 11.1 in.)
Antenna Type
- 2 x Internal Dual-Band Omni Antennas
- 2.4 GHz: 4.0 dBi
- 5 GHz: 5.0 dBi
Weatherproof Enclosure
- IP67
Mounting
- Pole/Wall Mounting (kits included)
Wireless Features
Concurrent Clients
- 1,020+
Wireless Standards
- IEEE 802.11 a/b/g/n/ac/ax
Frequency
- 5 GHz, and 2.4 GHz
Signal Rate
- 5 GHz: Up to 1201 Mbps
- 2.4 GHz: Up to 574 Mbps
Wireless Functions
- Mesh*
- Seamless Roaming (802.11k/v/r)*
- Automatic Channel Assignment
- Load Balance
- Band Steering
- Beamforming
- Airtime Fairness
- Multiple SSIDs (up to 16 SSIDs, 8 for each band)
- Wireless Statistics
- Wireless Schedule
- Reboot Schedule
- RADIUS Accounting
- MAC Authentication
- Static IP/Dynamic IP
Wireless Security
- VLAN
- Access Control
- Rogue AP Detection
- Captive Portal Authentication*
- Maximum number of MAC Filter: 4,000
- Wireless Isolation Between Clients
- WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
- 802.1X Support
Transmission Power
- CE: < 20 dBm (2.4 GHz, EIRP), < 30 dBm (5 GHz, EIRP)
- FCC: < 25 dBm (2.4 GHz), < 25 dBm (5 GHz)
Management
Omada App
- Yes
Restore & Backup
- Yes
Firmware update via Web
- Yes
NTP
- Yes
Centralised Management
- Omada Hardware Controller (OC200/OC300 - see accessories tab)
- Omada Software Controller
- Omada Cloud-Based Controller
Cloud Access
- Yes, requires the use of OC300/OC200 (sold separately), the Omada Software Controller, or Omada Cloud-Based Controller
Email Alerts
- Yes
LED ON/OFF Control
- Yes
Management MAC Access Control
- Yes
SNMP
- v1, v2c, v3
SSH
- Yes
Web-based Management
- Yes
Other Specifications
Certification
- CE, FCC, RoHS
Environment
- Operating Temperature: -30°C – 70°C (-22°F – 158°F)
- Storage Temperature: -40°C – 70°C (-40°F – 158°F)
- Operating Humidity: 10% – 90% non-condensing
- Storage Humidity: 5% – 90% non-condensing
Package Contents
- 1 x EAP623-Outdoor HD
- 1 x Mounting Kit
- 1 x Waterproof Kit
- 1 x Installation Guide
*Omada Mesh, Seamless Roaming, Cloud Access, and Captive Portal require the use of Omada SDN controllers.
