Ajax 12V PSU for Hub / HubPlus / ReX
Product Ref: 17938.54.NC
MPN: 17938.54.NC
A power supply unit, connecting Hub/Hub Plus control panels and ReX radio signal range extender to low-voltage power sources.
Use Ajax in premises lacking electricity or having an unstable power supply. A 12 V power supply unit allows connecting hubs and radio signal extenders to low-voltage networks or use a portable battery
Technical Specifications
- Input voltage 8-20 V DC
- Output voltage 4.65 V DC ± 3%
- Switch on voltage 8 V DC ± 2.5%
- Switch off voltage 6.9-7.5 V (depending on load)
- Max input current < 1 A
- Max output current 1,5 A
- Connection to mains, Socket: 6.5 × 2 mm Plug: 5.5 × 2,1 mm
- Dimensions 138 × 64 × 13 mm
- Weight 30 g
