Blustream 4x4 HDBaseT3™ AV Matrix Kit100m uncompressed, unconverted HDMI 2.0 4K 60Hz
Product Ref: HMX44-18G-KIT
MPN: HMX44-18G-KIT
The HMX44-18G Matrix kit is an industry leading uncompressed, unconverted HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.3/2.2 solution utilising HDBaseT™ 3 technology to deliver HDMI, bi-directional IR & RS-232, ARC / Optical S/PDIF return, 1Gb Ethernet, and PoC up to lengths of 100m over a single CAT6A cable.
The HMX44-18G supports uncompressed distribution of the latest HDR resolutions including HDR10/10+ and Dolby Vision resulting in the ultimate in picture quality for your critical viewing areas.
The Matrix also provides advanced features including simultaneous HDBaseT™/HDMI on output 1, video smart scaling on HDBaseT™ outputs, and an independent 14x4 audio matrix, with ARC and Optical audio return.
The HMX44-18G includes an in-built web browser interface module for control and configuration of the Matrix, and RS-232, IR and 1Gb Ethernet pass through to enable seamless 3rd party control integration.
Product Features
- Advanced uncompressed, unconverted, HDMI over HDBaseT3 technology offering distribution of bit-for-bit 4K HDMI video and audio over a single CAT6A cable.
- Features 4 x HDMI inputs which can be independantly routed to 4 x HDBaseT outputs.
- Output 1 features a simultaneous HDMI and HDBaseT output.
- Supports distribution of uncompressed HDMI2.0 18Gbps specification including 4K 60Hz 4:4:4 UHD video up to 100m*
- Supports distribution of the latest HDR resolutions including HDR10/10+ and Dolby Vision.
- 14x4 Audio Matrix independantly controllable from video.
- Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission.
- Integrated Ethernet switch (LAN Serving) when used with Blustream RX18G receiver (1Gb maximum)
- Web interface module for control and configuration of the matrix.
- Supports bi-directional IR and RS-232 on all HDBaseT outputs
- Control via front panel, IR, iOS/Android App, RS-232 and TCP/IP
- Supports PoC (Power over Cable) to power the supplied HDBaseT receivers
- Advanced EDID management and HDCP 2.3 compliant
- Supplied with 4 x RX18G HDBaseT Receivers
