SB-2 Passive Soundbar

Product Ref: SB2B

The compact SB-2 is engineered for seamless integration with 50-60 inch TVs, featuring three separate driver arrays for left, centre, right channels in a single cabinet.

Technical Specifications

Frequency Response (-3 dB)

90 Hz – 30 kHz

Sensitivity (1W@1M)

84 dB

Nominal Impedance

8 ohms

Power Handling (RMS)

40 W

System Power Handling (RMS)

100 (High pass filter set to 100 Hz)

Recommended Enclosure

30 — 100 W

Crossover Frequency

80 — 120 Hz

Maximum SPL

104 (108.8 all channels driven)

Bass Alignment

3 x Auxiliary Bass Reflex (ABR) Loading

Drive Unit Complement

3 x 4" (100 mm) C-CAM cone bass/mid driver
3 x 1" (25 mm) C-CAM Gold Dome tweeter

Cabinet Dimensions: (H x W x D) (Including Feet)

147 x 1107 x 93 mm (513/16 x 439/16 x311/16")

External Dimensions (Including Bracket (H x W x D))

145 x 1107 x 100 mm (511/16 x 439/16 x 315/16")

Bracket

BSB

Weight

7.64 kg (16 lb 12 oz)

Sold As

Single Unit

Product Features

The SB-2 employs individual 4 inch C-CAM mid-bass, 1 inch C-CAM tweeter and sealed ABR (Auxiliary Bass Radiator) drivers per section.

In larger rooms the SB-2 can be used with a partnering Monitor Audio subwoofer to deliver the best possible audio experience. Within smaller environments and systems, the SBs will deliver effortless full range audio way beyond the limits of any TV's sound system.
