Climate Garden CLG160

Product Ref: SCLG160BR

Suitable for ground level installation within the garden and around decking areas or mounted onto a tree, pole or garden fence, the new CLG160 speaker features a rigid polymer shell which ensures it is resilient to extreme weather conditions.



Installation is simple, thanks to the requirement for the speaker to be wired in a mono configuration and powered by one amplifier channel. The other amplifier channel can be used to power the subwoofer. This configuration allows the levels between bass and mid-high range to be easily equalised. Alternatively, the system can be designed to provide stereo operation if desired by creating stereo left/right zones.

Despite being installed outside, the aesthetics of the speakers are just as important. Finished in dark brown, the CLG160 blends seamlessly into this environment to provide high quality sound for outdoor entertainment, whilst not distracting from the landscape. The speaker casing can be painted a different colour, if required.

Technical Specifications

Frequency Response (-6 dB)

80 Hz — 30 kHz

Sensitivity (1W@1M)

89 dB

Line Level Voltage

70/100 Volt line level

Maximum SPL

107 dBA

Power Handling (RMS)

60 Watts (crossover set to minimum 80 Hz @12 dB/Octave)

Recommended Amplifier Requirements

10 — 60 W per speaker

Drive Unit Complement

1 x 6" MMP II cone bass-mid driver
1 x 25 mm C-CAM Gold Dome tweeter – Coaxially oriented

Crossover Frequency

80 Hz at a minimum of 12 dB/Octave (24 dB/Octave optimum)

External Dimensions (Excluding Spike and Mount (H x W x D))

190 x 220 mm (71/2 x 811/16")

Total Bracket Pivot Angle

180 degrees

Connection

Encapsulated cable connection

Environmental Protection Rating

IP55

Operating Temperature Range

-20° to 70° C / -4° to 158° F

Colour / Finish

Dark Brown

Dispersion

60 degrees

Weight

2.76 kg (6 lb 2 oz)

Sold As

Single Unit

Product Features

  • Purposely designed 6" MMP II bass-mid range driver
  • 25 mm C-CAM Gold Dome tweeter – coaxially mounted
  • 70/100v line level operation –internal matching transformer
  • Tree or pole mounting possible with additional fixings
  • Garden spike (CLG-SPIKE R) and mount (CLG-MOUNT) available separately
  • PTC overload protection against power overload
