MonitorAudio Apex A10 *WHITE* (Single)

Technical Specifications

Frequency Response

60 Hz — 35 kHz

Sensitivity (1W@1M)

87 dB

Drive Unit Complement

1 x 140 mm (51/2") RST mid-bass driver
1 x 25 mm (1") C-CAM Gold Dome tweeter

Nominal Impedance

8 ohms

Maximum SPL

110.8 dBA

Recommended Amplifier Requirements

25 — 100 W

Bass Alignment

Front ported - bass reflex. HiVE II port system

Power Handling (RMS)

100 W

Crossover Frequency

3.0 kHz

External Dimensions (Cabinet Only (H x W x D))

250 x 140 x 140 mm (913/16 x 51/2 x 51/2")

External Dimensions (Including Table Stand (H x W x D))

280 x 150 x 180 mm (11 x 57/8 x 71/16")

Weight (each)

3.95 kg (8lb 11 oz)

Sold As

Single Unit

Product Features

• 51/2" C-CAM Driver with RST dimpled cone geometry for rigidity
• 1" Gold C-CAM Tweeter
• HiVe II High Velocity reflex port; delivers smoother airflow for better transient response and tighter bass
• Dedicated Internally Wired Stand available
• Can be mounted on wall, ceiling or table top with dedicated robust bracket
• Magnetic Grilles; for the sleekest effect there are no visible fixings
• Rigid die-cast alloy cabinet
• Finished in luxurious metallic black high gloss or metallic pearl white high gloss
